Holding Solenoids – DC coils, external diameters ranging from 30-70mm, “F” class insulation and “H” class wound wire available with flying leads or spade terminals electrical connections.

Linear Solenoids – galvanised steel body or with encapsulated coils, “F” class insulation and wound with a “H” class wire.

Encapsulated Coils – choice of power supply, materials and electrical connections.

Pinch Solenoid ValvesĪn extensive range of SIRAI solenoid coils are available: T&D can provide expert technical advice and sales support for the specification of solenoid valves to provide safe refrigerant gas flow control and also refrigerant gas detection. SIRAI valves integral with HNBR (Hydrogenated Nitrile Butadiene‎) are proven to shut-off and control flow of common refrigerant gases. The extreme volatility of refrigerating gases necessitates modified solenoid valves and specialised sealing systems must be used. These power absorptions are measured by energising the solenoid coil at nominal voltage at an ambient temperature of 20☌.

💡 Did You Know? Power Absorption – power absorption indicates the power during inrush and holding for AC (VA) and the ‘cold’ absorbed power for DC (W).

The bi-stable control limits power consumption to the valve switching phase – the combined action of electric winding and permanent magnet ensures the solenoid valve switches from the open to closed position (or vice versa) by means of a simple pulse in a few milliseconds. Where general service solenoid valves have a power absorption which exceeds the process application requirement a latching coil can be installed to the valve. Customised valves can be produced with materials and performance specification to meet specific application requirements.

#Electric solenoid valve factory plus

Micro solenoid valves are available in 2/2 or 3/2 normally closed, open or universal service versions plus proportional control and latching type. SIRAI micro solenoid valves are specified for limited space applications demanding a compact valve with small size, low power, control components – micro solenoid valves control a variety of non-aggressive liquid and gaseous fluids and can be disassembled for cleaning and maintenance.

VDI/VDE 2173 Fluidic Characteristic Quantities Of Control Valves & Their Determination.

💡 Did You Know: Flow Rate – the flow rate of a valve is indicated by the flow factor Kv, which represents the quantity of water, expressed in m /h, that flows through the solenoid valve with a pressure drop of 1 bar and a temperature between 5☌ and 30☌ ( Standard VDI/VDE 2173). Standard brass body solenoid valves are available with gas female threaded ports (ISO 228) for sub-base mounting or NPT connections – stainless steel, nickel plated brass, aluminium and PP solenoid valves also available.

Flow rate regulation of spray nozzles for small cooling systems.

Vacuum regulation for medical electronic or cosmetic treatment equipments.

Gas flow rate regulation – blowers, diaphragm pumps, venturi meters.

Standard coil：ACPneumatic power 6VA,stable power 4.3VA((hot)DC2.

#Electric solenoid valve factory manual

※ Manual switch, in situ testing when blackoutįiltration(50mm lubrication or compressed air ,-20℃ dew point) ※ two position five-way can be directly converted into two position three-way ※ specialized O-ring, no need for the second lubrication

※ ISO228 / 1 standard, easy installation. At the same time two position three-way, five-way ,two five, electric control and double electric control products are as options. It conforms to the NAMUR connection standard and is installed directly at the actuator’s air supply interface. Pneumatic solenoid valves to open or close the pneumatic valve.
